The UCP series Pillow block bearing are composed of an outer spherical bearing and a cast (or stamped) bearing seat combination. The outer ring adopts a truncated spherical design, and the automatic centering function is achieved through the concave spherical surface of the bearing seat. This product adopts the fixing method of top thread, eccentric sleeve or tight fitting sleeve, and the structural characteristics of the inner ring being wider than the outer ring make it have both the operational performance of deep groove ball bearings and the convenient installation advantages of seat bearings. As an industrial basic component, it is widely used in simple support scenarios in mining, metallurgy, agricultural machinery and other fields.

Product characteristics

Automatic centering: The spherical surface of the outer ring matches the concave surface of the bearing seat, which can compensate for shaft deviation of 0.5 ° -2 °

Convenient installation: The integrated structure simplifies the assembly process, and the bearing components can be replaced separately during maintenance

Sealing protection: Double sided contact sealing design effectively blocks dust intrusion

application area

Mainly serving industrial scenarios that require simple support, including:

1. Mining Machinery: Belt Conveyor Roller Support

2. Agricultural equipment: transmission system of combine harvester

3. Textile machinery: yarn guide roller support structure

4. Material conveying: Rotating components of drum conveyor line
